Sumry 4000W Hybrid Solar Inverter 24V 120V Pure Sine Wave MPPT
Sumry 4000W Hybrid Solar Inverter 24V 120V Pure Sine Wave MPPT
The Sumry 4000W Hybrid Solar Inverter is a 24V off-grid power solution that outputs 110-120V pure sine wave electricity for home appliances. Designed for energy management, it features a 140A MPPT solar charger capable of handling up to 5600W of PV input, ensuring efficient power conversion for off-grid setups.
Key features
- Pure Sine Wave Output – Delivers clean electrical power compatible with sensitive home electronics and personal computers.
- Battery-Free Operation – Provides the flexibility to run the system without a connected battery.
- Integrated MPPT Charger – Built-in 140A solar charger supports up to 5600W of PV input with a wide 55V-350Vdc range.
- Smart LCD Interface – Features a 6.25-inch glass-top display with touch-sensitive buttons for configuration and monitoring.
- Protection Systems – Includes automatic alerts and protection against over-load, over-temperature, and output short circuits.
- Cold Restart Function – Allows the inverter to restart and restore power even when no utility or battery source is immediately available.
Specifications
| Rated Power | 4000W |
|---|---|
| Battery Voltage | 24VDC |
| Output Voltage | 110-120VAC |
| PV Input Range | 55-350Vdc |
| Max Charge Current | 110A |
| Dimensions | 400 × 250 × 89 mm |
| Weight | 9 kg |
| Efficiency | 98% |
| Transfer Time | 10ms (computers) / 20ms (appliances) |
| Communication | RS232/RS485 |
Ideal for
This inverter is ideal for off-grid residential setups or remote cabins requiring a reliable 120V power supply from solar arrays. It is well-suited for users who need to power home appliances and computers with the flexibility to operate with or without a battery bank.
FAQ
Does it work without a battery?
Yes, this inverter supports battery-free operation as a native feature.
What is the maximum solar input power?
The built-in MPPT solar charger supports a maximum PV input of 5600W.
Can this power sensitive electronics?
Yes, the inverter produces a pure sine wave output, which is the required standard for powering personal computers and sensitive home electronics safely.
How do I monitor the system?
You can monitor the system via the 6.25-inch LCD display on the unit, or use the optional WiFi monitoring function and standard RS232/RS485 ports.
